FranklinWH is focused on energy management solutions providing safety, reliability and energy independence for homes. Franklin Home Power (FHP) is a whole-home energy management system integrating solar, battery, grid and generator power sources and managing them to optimise the safety, reliability and efficiency of home energy. The FHP is designed for simplicity and is easy to install, maintain and operate.
FranklinWH is a research-driven company focused on next-generation residential energy management and storage solution. Founded in 2019, headquartered in the San Francisco Bay Area, and funded by Sequoia Capital, FranklinWH’s team has decades of experience in energy systems, from design, through manufacturing, to sales and installation. FranklinWH is also AVL listed with multiple financial institutions.
![](/web/image/211571-4080b585/FranklinWH%20-%20How%20it%20works.png)
AC Solar Warehouse – FranklinWH Energy distributors/wholesalers Australia and New Zealand
AC Solar Warehouse is an Australian and New Zealand FranklinWH distributor/wholesaler with warehouses in Brisbane, Sydney, Melbourne, Adelaide, Perth, Cairns, Auckland and Christchurch.
AC Solar Warehouse are experts in FranklinWH technologies with 100+ years of combined engineering experience in solar and storage.
Franklin Home Power
Energy Capacity
13.6kWh usable capacity per aPower
Up to 15 aPowers per aGate, 204kWh capacity
Protection Performance
Two smart circuits available for auto load-shedding
Backup Power
5kW continuous output /10kW peak
43MWh aggregated throughput
Environmental
Max. 4000m of altitude
Operating temperature : -20°C to 50°C
aPower water and dust resistance rate: IP67
Certifications
Meets safety standards and regulations in the US, Europe, and Australia
Warranty
12 years
![](/web/image/211775-badf5fec/Franklin%20Battery%20Australia.png)
aPower
Performance
- Energy capacity: 13.6kWh
- 5kW continuous power / 10kW peak power (10s)
- 100% depth of discharge
- 89% round trip efficiency
Environmental
- Max. 4000m of altitude
- Operating temperature: -20°C to 50°C
- Ingress rating: IP67 (Battery and power converter system), IP56 (Wiring compartment)
Mechanical
- Dimensions (H x W x D):1150 x 750 x 290mm
- Weight: 185kg
- Installation: indoor or outdoor / wall mount or floor mount
Certifications
IEC / EN62109-1, IEC / EN62109-2, UL1973, IEC / EN62477-1, AS/NZS 4777.2:2020, IEC62040-1, IEC / EN62619
![](/web/image/211776-3951b52c/franklin%20solar%20battery%20Australia%20%283%29.png)
aGate
Performance
- Up to 15 aPowers scalability per aGate
- Maximum supply fault current: 10 kA
- Communications: Ethernet / 4G / Wi-Fi / Bluetooth
Environmental
- Max. 4000m of altitude
- Operating temperature: -20°C to 50°C
- Ingress rating of IP55
Mechanical
- Dimension (H x W x D): 650 × 480 × 160 mm
- Weight: 23kg
- Installation: indoor or outdoor / wall mount
Certifications
IEC / EN62109-1, IEC / EN62109-2, IEC / EN62477-1, AS/NZS 4777.2:2020, IEC62040-1,
IEC / EN61439-1, IEC / EN61439-2
![](/web/image/211777-7eb4cbb8/franklinWH%20aGate%20Australia%20solar%20installer.png)
aGate
Performance
- Up to 15 aPowers scalability per aGate
- Maximum supply fault current: 10 kA
- Communications: Ethernet / 4G / Wi-Fi / Bluetooth
Environmental
- Max. 4000m of altitude
- Operating temperature: -20°C to 50°C
- Ingress rating of IP55
Mechanical
- Dimension (H x W x D): 650 × 480 × 160 mm
- Weight: 23kg
- Installation: indoor or outdoor / wall mount
Certifications
IEC / EN62109-1, IEC / EN62109-2, IEC / EN62477-1, AS/NZS 4777.2:2020, IEC62040-1,
IEC / EN61439-1, IEC / EN61439-2
