SolarEdge Home Hub inverter - 10kW (single phase)
Hybrid inverter compatible with SolarEdge Home Battery (backup capable)
Requires SolarEdge optimisers to operate
SolarEdge energy meter built into inverter - CT(s) sold separately
Directly connects to up to 3 SolarEdge Home Batteries
BI-NAUGN-01 Backup Interface required for backup functionality
This product is no longer available.
One Inverter. Many Functions.
The SolarEdge Energy Hub inverter brings together the capabilities of all of SolarEdge's existing residential inverters in a single solution. Not only is it DC-coupled battery-ready, it is preconfigured to connect to SolarEdge's Level 2 Smart EV Charger for driving on up to 100% sunshine. And with a built-in consumption meter, it becomes easier to track usage and reduce bills. It is future-ready, enabling an ever-growing range of products to be added on to meet evolving household needs.
A Breakthrough in Battery Backup
The superior performance of HD-Wave and StorEdge come together to offer advanced home storage. When installed with a battery and backup interface, the SolarEdge Energy Hub DC-coupled solution provides high energy yield, allowing larger installs.- 200% DC oversizing allows for larger systems: energy that would normally be lost in an AC-coupled solution can now be redirected to a battery for optimizing self-consumption
- 90.8% overall system efficiency
- More loads can be backed up to 200A - full home or partial
- Power stack batteries for increased production and storage to keep the entire home covered*
- Generator compatible*
To find out more about SolarEdge Energy Hub please click here Which inverter to use? HD-Wave Genesis or Energy Hub? Click here for details Frequently asked questions about the Energy Hub and backup interface? Click here for details
Sungrow 110kW Three Phase Hybrid Inverter
SKU: SH110CX
The Sungrow 110kW Three Phase Hybrid Inverter (SKU: SH110CX) represents a major breakthrough in commercial and industrial (C&I) energy storage solutions. Engineered for both grid-connected and off-grid installations, this high-capacity hybrid inverter combines PV solar generation, energy storage battery management, and grid interaction into a single powerful platform. Equipped with 10 MPPT trackers, up to 200% PV array oversizing, and an IP66 weatherproof rating with C5 anti-corrosion protection, the SH110CX offers maximum solar harvesting and reliable power backup for large commercial facilities, industrial sites, and microgrid applications.
Key Features: Sungrow 110kW Three Phase Hybrid Inverter
High Solar Yield & Multi-MPPT: Designed with 10 independent MPPT trackers and 40A max input per MPPT, accommodating modern high-power bifacial solar modules.
Massive PV Oversizing: Supports up to 200% DC PV array oversizing to maximize generation during low-light hours.
Exceptional Peak Backup Power: Delivers up to 165kW peak backup output (for 10 seconds) and 100% three-phase unbalanced load output during power outages.
PID Zero Technology: Features built-in, industry-exclusive 24-hour anti-PID protection to prevent degradation and maintain long-term module performance.
Advanced Safety Integration: Equipped with AFCI 3.0 intelligent DC arc interruption, string-level protection, and Type I+II DC / Type II AC surge protection (SPD).
High Scalability: Supports parallel operation of up to 24 inverters via Logger1000 and pairs seamlessly with commercial high-voltage battery storage systems.
Harsh Environment Ready: Heavy-duty IP66 ingress protection and C5 anti-corrosion rating ensure durable outdoor operation.
Basic Specs: Sungrow 110kW Three Phase Hybrid Inverter
Rated AC Output Power: 110 kW / 110 kVA
Max. AC Output Current: 158.8 A
Nominal AC Voltage: 3 / N / PE, 220 V / 380 V, 230 V / 400 V
Max. PV Input Voltage: 1100 V
MPPT Operating Voltage Range: 180 V - 1000 V
No. of MPPT Trackers / Strings per MPPT: 10 MPPTs / 2 Strings per MPPT
Max. Efficiency: 98.5%
Grid Connection / Backup Switching Time: less than or equal to 10 ms
Battery Voltage Range: 129 V - 880 V
Dimensions (W x H x D): 1095 x 795 x 360 mm
Weight: 123 kg
Protection Class & Corrosion Level: IP66 / C5
Standard Warranty: 10 Years
What’s Included: Sungrow 110kW Three Phase Hybrid Inverter
Sungrow 110kW Three Phase Hybrid Inverter (Model: SH110CX)
Built-in DC Switch and Protective DC Wiring Cover
Heavy-Duty Wall Mounting Bracket
Standard MC4 Connectors & OT/DT AC Terminals
Wireless Communication Module (WLAN / Bluetooth / 4G support)
User Manual & Installation Guide
Why Choose AC Solar Warehouse for Sungrow 110kW Three Phase Hybrid Inverter?
When sourcing the Sungrow 110kW Three Phase Hybrid Inverter through AC Solar Warehouse, you benefit from industry-leading commercial solar expertise, guaranteed authentic equipment, and dedicated technical service. AC Solar Warehouse offers end-to-end support for commercial and industrial installers—from pre-sale system design and string sizing verification to post-commissioning assistance. With stock availability and robust logistics networks, AC Solar Warehouse ensures your commercial energy storage projects are executed efficiently and backed by trusted industry professionals.
