SKU: IQ8X-80-M-INT
Item ID: 3294

Secondary Network Protection and Solar Distribution board includes:
• Board Dimensions: 800(H) x 600(W) x 250(D) [mm]
• Board Colour: RAL 7035
• IP66
• Powder-coated steel with top and bottom gland plates
• Switchgear rated to 200A
• ABB Grid Protection Relay, pre-programmed to DNSP settings
• Fault rated to 18kA
• Fault current applies to entire assembly, complying with AS/NZS 61439.1:10
• For higher fault currents, please call ACSW to discuss
• 3-Point Locking System
• Pre-labelled with additional labels included for MSB
• Pre-wired and factory tested according to AS/NZS 61439.1: Clause 11
• Compliant to AS/NZS 3008.1.1:2017, AS/NZS 3000:2018, AS/NZS 5033:2021, AS/NZS 4777.1:2016, AS/NZS 61439.2:2016

- Available Modifications -
• Swap ABB Network Protection Relay for ComApp MainsPro (+$50)
• Install test links for injection testing (+$100)
• Install Generation Signalling Device (Queensland only) (+$100)
• Install 3P+N AC surge diversion (+$250)

SKU: 601982

*FREE SHIPPING

*Free shipping is eligible for up to a freight charge of $30 excluding GST. If the freight cost for your location exceeds $30, you will only be charged the excess amount at checkout.

IQ8AC-72-M-INT 360W microinverter with in-built DC connection plugs

SKU: 601983

IQ8HC-72-M-INT

**Trade up offer for singe phase systems ending on June 30th 2026, please plan carefully around ETAs for battery stock**

Compatible with SolarEdge residential inverters (Home Hub, Genesis & 3 Phase Residential)

Hybrid inverter compatible with SolarEdge Home Battery (backup capable)
Requires SolarEdge optimisers to operate
SolarEdge energy meter built into inverter - CT(s) sold separately
Directly connects to up to 3 SolarEdge Home Batteries
BI-NAUGN-01 Backup Interface required for backup functionality

Special accessory kit with spare 'dummy' SBR module to form an SBR064 stack

S440-1GM4MRM
Now supports connection of modules up to 520W/15A, see latest data sheet for details

sonnenBatterie sBEvo
Ethernet internet connection only per sonnen warranty - Wifi not supported

Kit includes:
- Carton 1 - 3000286 outdoor rated enclosure, inverter and plinth
- Carton 2 - 3000292 accessory kit (energy meter, CTs, MCBs, label kit etc.)
- Carton 3 - 4000630 5kWh battery module 1
- Carton 4 - 4000630 5kWh battery module 2

11452 sonnen LCD programming tool (sold separately) required to commission on 3 phase site

Installer training (required for commissioning): https://sonnen.com.au/become-installer/

Free delivery to metropolitan areas with forklift, or discounted freight for regional areas and metropolitan areas without forklift. Contact us for a tailored freight quote.

Internal cable space: 24mm x 23mm
Outer dimensions: 69mm x 53 x 38mm
Lead length: 0.9m

Internal cable space: 50mm x 50mm
External dimensions: 120mm x 100mm
Lead length: 0.9m

One power supply required per Coil CT kit
